Nuron

TE 6-22 Cordless rotary hammer

L126047 (228547)
L142719_HNA_cropped (1913142)
L142062_cropped (2209199)
L142718_HNA_cropped (1913130)
L142505_cropped (2209237)
L147307_cropped (2807678)
L126047 (228547)
L142719_HNA_cropped (1913142)
L142062_cropped (2209199)
L142718_HNA_cropped (1913130)
L142505_cropped (2209237)
L147307_cropped (2807678)
NCP_SC_TE6_Promo_16_9_EN_HNA_v4 (1948027)

Versatile SDS Plus cordless rotary hammer with wide drilling range, chipping function and quick-change chuck (Nuron battery platform)

  • Tool Service 01: 3 or free: get the tool serviced and cleaned in 3 days flat or there is no charge
  • Weight according EPTA Procedure 01/2003 without battery: 2.84 kg
  • Optimum hammer drilling range: 6 - 18 mm

Customers also searched for cordless rotary hammer drill, cordless drill hammer, hilti cordless rotary hammer drill, cordless sds drill or cordless sds rotary hammer drill.

Technical Data

Tool Service 01
3 or free: get the tool serviced and cleaned in 3 days flat or there is no charge
Weight according EPTA Procedure 01/2003 without battery
2.84 kg
Optimum hammer drilling range
6 - 18 mm
Tool Service 06
Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
Single impact energy
2.6 J
Tool Service 10
After the no-cost period, repair costs are capped
Hammer drilling diameter range
4 - 28 mm
Hammer drilling RPM
1050 rpm
Full hammering frequency
5100 impacts/minute
Functionality
Active Torque Control (ATC), Active Vibration Reduction (AVR), Chiselling, Chipping, Depth gauge, Removable chuck, Reverse mode, Torque clutch
Triaxial vibration value for hammer drilling into concrete (ah,HD)
10.7 m/s² 1
Triaxial vibration for chiselling in concrete
5.5 m/s² 2
A-weighted emission sound power level
102 dB (A) 3
A-weighted emission sound pressure level
94 dB (A) 4
Dust removal system available
TE DRS-4/6, TE DRS-C, TE DRS-D
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see the Operating Instruction for more details)
  3. According to the applicable product standard (see the Operating Instruction for more details)
  4. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Features & Applications

Features

  • Performance, versatility and ergonomics in one – the TE 6-22 cordless rotary hammer has a wide drilling range, chiselling function and more comfort for all-day use
  • Helps reduce fatigue – now even lighter, helping you power through larger concrete drilling jobs
  • Improved handling – better tool balance and contoured grips so you can drill, chip or drive more comfortably in any position
  • Comprehensive safety features – includes Active Torque Control (ATC) to better protect you from uncontrolled spinning if the bit sticks
  • Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity

Applications

  • Drilling and hammer drilling in concrete and masonry
  • Virtually dust-free drilling (TE DRS-4/6 on-board dust removal system or TE DRS-C vacuum cleaner connector required)
  • Light-duty chiselling – such as tile scraping, channel cleaning or surface correction
  • Occasional drilling in wood and steel (with optional quick-release chuck)
  • Setting anchors and drop-in anchors (with optional TE-C bit holder)

For approval or certificate information, please see individual items.

Hilti Tool Service

Hilti Tool Service

  • Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
  • After the no-cost period, repair costs are capped
  • Product warranty against parts and manufacturing irregularities for as long as we service the tool
  • 3-month no-cost period after each paid repair
More information about Tool Services

Fleet Management

  • Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
  • High-performing tools and latest technology help to increase jobsite productivity.
  • Loan tools during repair to reduce downtime.
  • Temporary tools for peak times and special applications help to reduce investments.
  • Theft coverage helps to reduce financial risk and unexpected expenses.
More information about Fleet Management
